Filling The God-Shaped Gaps - How Bone Evolved

An impression of the placoderm fish living 380 million years ago.

© Brian Engh/dontmesswithdinosaurs.com

Tomography brings insights into the early evolution of bones - Helmholtz-Zentrum Berlin (HZB)

When bone first appeared in the fossil record, it did not contain the bone cells (osteocytes) that are today considered essential for normal bone growth and development, so where did they come from? This is the sort of gap any diligent Creationist would look for and, when found, would plonk their god firmly in it, declare the fit to be perfect and proclaim the question answered, in the only way permitted to a Creationist - God did it!

But, as usual, when science looks in these gaps, Creationism's god is nowhere to be seen. Instead, they find it was never there at all because it was merely an illusion caused by gaps in the record, not gaps in the entirely natural processes that brought about the world as we see it today. As always, what is evolved out of what was, without magic or the involvement of a clever invisible magic sky man.

Just such a gap was closed recently by a team of scientists working for the Museum für Naturkunde Berlin, headed by Dr Florian Witzmann who used the focussed ion beam of a scanning electron microscope at the Helmholtz-Zentrum Berlin (HZB) to examine the bone structures of 400 million year-old fossils of marine life in nanometre-scale, to calculate unprecedented 3D detail. The scientists believe they have even identified the environmental factor which drove this evolution - a shortage of the essential mineral, phosphorus.

As the Helmholtz-Zentrum press release explains:

Modern biology considers bone cells (osteocytes) as essential for bone development and health. However, when bone initially evolved some 400-million years ago, it did not contain bone cells. So why did bone cells evolve? Why was it so advantageous that most subsequent vertebrates have bone cells? A joint team of palaeontologists at Berlin’s natural history museum has now for the first time analysed these structures in 400 million-year-old fossils of marine life at unprecedentedly high resolution and in 3D. To be able to view these structures, tomography experts at the Helmholtz-Zentrum Berlin (HZB) examined the samples under the focussed ion beam of a scanning electron microscope to calculate 3D images from the data, achieving resolutions in the nanometre range using technology that was initially developed to study battery corrosion.

Using a neural net trained on battery electrodes, the HZB scientists succeeded in calculating 3D images from the fossil bone samples with nanometer-scale resolutions.

© HZB

Whether fish, fowl, or mammal, all vertebrates have an internal skeleton of bones. In almost all vertebrates (with the exception of certain bony fish), the bone consists of a complex composite of minerals, proteins, and living bone cells (osteocytes) entrapped in the bone matrix. The bone cells are interconnected by tiny channels so that they can exchange substances and electrochemical signals, allowing the bone to grow and regenerate. Still, this complex architecture of live and inorganic material must have emerged at some point in the course of evolution. A team at the Museum für Naturkunde Berlin headed by Dr Florian Witzmann is investigating how and when this happened. Now they have discovered a possible milestone in this development.

Image data from the fossil bone sample shows the bone cell and its tiny connecting channels, which are thousands of times finer than a hair.

© HZB

Two fish species from 400 mio years ago

They have examined fossilised samples of bony armour from two early fish species that lived around 400 million years ago. One sample came from Tremataspis mammillata, a jawless fish that lived in the late Silurian period about 423 million years ago and belongs to the extinct group called Osteostraci. The second, much younger sample was a piece of bone from the fish Bothriolepis trautscholdi that lived in the late Devonian period about 380 million years ago and belongs to the extinct Placodermi, the earliest group of jawed fishes. “It was already known that these early vertebrates had bone cells, but we knew little about

It was already known that these early vertebrates had bone cells, but we knew little about how the cells were connected to each other, as well as anything about the detailed structure of the lacuna, or cavities, in which the bone cells were located in the living animal. In order to be able to make more precise statements about bone metabolism, we had to have far more detailed images of these structures than were previously available.

This proves that our early, still-jawless ancestors already possessed bones characterised by internal structure similar to ours and probably by many similar physiological capabilities as well.

Dr. Florian Witzmann, Co-author
Museum für Naturkunde
Leibniz-Institut für Evolutions-und Biodiversitätsforschung, Berlin, Germany.

how the cells were connected to each other, as well as anything about the detailed structure of the lacuna, or cavities, in which the bone cells were located in the living animal. In order to be able to make more precise statements about bone metabolism, we had to have far more detailed images of these structures than were previously available”, says Witzmann.

Tomography at HZB

To achieve this, HZB expert Dr. Ingo Manke suggested a method that is available at the HZB campus in Wannsee in the Electron Microscopy Laboratory: focussed ion-beam scanning electron microscopy (FIB-SEM) tomography on the ZEISS Crossbeam 340. In this device, a focussed gallium-ion beam continuously ablates material from the sample surface, gradually digging its way deeper into the sample. At the same time, an electron beam scans the freshly revealed part of the sample and provides data for creating 3D images at a resolution that is more than a hundred times finer than computer tomography.

Due to the countless paths through the bone, the sample surface is as full of holes as Swiss cheese. In fact, the structures in the bone samples are relatively similar to the structures in the electrode materials of batteries. But the fact that the neural network, which learned on battery materials, can now also image the fossil bone samples so well surprised us.

Markus Osenberg, Co-author
Physicist & PhD student at HZB, Berlin, Germany

Image construction by neural network trained on battery electrodes

Manke's team had already used this method to study electrode materials for batteries, which have a network of fine paths for transporting ions. HZB physicist Markus Osenberg had previously employed a sophisticated evaluation procedure developed at HZB's 3D Analytics Lab to calculate the image from the measurement data. This is a specially trained neural network, a method borrowed from machine learning, because images of these kinds of samples cannot be calculated using standard methods. “Due to the countless paths through the bone, the sample surface is as full of holes as Swiss cheese”, explains Osenberg, who is doing his doctorate in Manke's team. However, after some practice, the well-trained neural network recognises where the plane of the ablation runs and where the holes are, and reconstructs an accurate image of the ablated surface. “In fact, the structures in the bone samples are relatively similar to the structures in the electrode materials of batteries. But the fact that the neural network, which learned on battery materials, can now also image the fossil bone samples so well surprised us”, says Osenberg.

The channels are a thousand times narrower than a human hair and yet, amazingly, they have been almost completely preserved over these 400 million years.

Dr. Ingo Manke, Co-author
Electron Microscopy Laboratory
HZB, Berlin, Germany

Interconnecting channels

Even in the older sample of the jawless armoured fish, the 3D images display a complex network with cavities (lacunae) for the bone cells and tiny channels through the bone interconnecting these cavities. “The channels are a thousand times narrower than a human hair and yet, amazingly, they have been almost completely preserved over these 400 million years”, says Manke.

The most important palaeobiological finding is that we can also detect actual traces of metabolism in these earliest bone samples. This advantage apparently led to the widespread establishment of bones with bone cells in vertebrates, as we know it in humans as well. It is an important step towards understanding how our own bone metabolism came about.

Even in early fossil bone, bone cells could dissolve and restore bone minerals, this means that bones themselves act as batteries by storing minerals and releasing them later! This ability provided an undoubtable advantage to jawless fish with bone cells over vertebrates without. This advantage was possibly so profound as to alter vertebrate evolution, as later jawed vertebrates retained bone cells.

Yara Haridy, Lead author
PhD Student Museum für Naturkunde, Berlin, Germany.

Ancient bone structure similar to ours

Elaborate analysis of the high-resolution 3D images shows in detail how the network was constructed of cavities (lacuna) and the channels between them. “This proves that our early, still-jawless ancestors already possessed bones characterised by internal structure similar to ours and probably by many similar physiological capabilities as well”, Witzmann explains.

Traces of metabolism

“The most important palaeobiological finding is that we can also detect actual traces of metabolism in these earliest bone samples”, says Yara Haridy, who is doing her PhD at the Museum für Naturkunde Berlin. Through local osteolysis, i.e. dissolution of the bone matrix that surrounded the bone cells, the organism was probably able to cover its need for phosphorus in times of scarcity. This gave it an advantage over its more primitive contemporaries, who had cell-free bone, i.e. whose bones contained no osteocytes. “This advantage apparently led to the widespread establishment of bones with bone cells in vertebrates, as we know it in humans as well. It is an important step towards understanding how our own bone metabolism came about”, Haridy explains.

Bones storing minerals "like a battery"

As a summary, she emphasizes: “Even in early fossil bone, bone cells could dissolve and restore bone minerals, this means that bones themselves act as batteries by storing minerals and releasing them later! This ability provided an undoubtable advantage to jawless fish with bone cells over vertebrates without. This advantage was possibly so profound as to alter vertebrate evolution, as later jawed vertebrates retained bone cells”.

The research findings were published open access a few days ago in Science Advances:

Abstract

Lacunae and canaliculi spaces of osteocytes are remarkably well preserved in fossilized bone and serve as an established proxy for bone cells. The earliest bone in the fossil record is acellular (anosteocytic), followed by cellular (osteocytic) bone in the jawless relatives of jawed vertebrates, the osteostracans, about 400 million years ago. Virtually nothing is known about the physiological pressures that would have initially favored osteocytic over anosteocytic bone. We apply focused ion beam–scanning electron microscopy tomography combined with machine learning for cell detection and segmentation to image fossil cell spaces. Novel three-dimensional high-resolution images reveal areas of low density around osteocyte lacunae and their canaliculi in osteostracan bone. This provides evidence for demineralization that would have occurred in vivo as part of osteocytic osteolysis, a mechanism of mineral homeostasis, supporting the hypothesis that a physiological demand for phosphorus was the principal driver in the initial evolution of osteocytic bone.

Haridy, Yara; Osenberg, Markus; Hilger, André; Manke, Ingo; Davesne, Donald; Witzmann, Florian
Bone metabolism and evolutionary origin of osteocytes: Novel application of FIB-SEM tomography
Science Advances 31 Mar 2021: Vol. 7, no. 14, eabb9113; DOI: 10.1126/sciadv.abb9113

Copyright: © 2021 The authors. Published by the American Association for the Advancement of Science
Open access Reprinted under a Creative Commons Attribution 4.0 International License (CC BY 4.0)

And so, without the slightest intent, in the time-honoured tradition of scientific discovery, scientists evict Creationism's ever-shrinking god from yet another gap, simply by filling it with evidence, and fantasy gives way to fact yet again.

---
